Fork Terminal Blade Connector Wire Connector BEYF

  • Fork Terminal
  • PIN Terminal
  • PIN Terminal
  • PIN Terminal
Category:

Insulated Fork Terminal Blade Connector Wire Connector BEYF

Specification:

Material: Copper, Tin-plated copper
Insulated Material: PVC
Certification: CE, RoHS, UL Approved
Working Temperature: -40℃ to 85℃ Heat-resistance
Insulated Fork Terminal offers a termination security in high vibration areas. All these Terminals are made of high-quality copper in good conductivity and corrosion resistance.

Item No. AWG/mm² d2 B L F H Color
BEYF1.25-3 22-16
0.5-1.5
19A
1000PCS
3.2mm 5.7 21.2 6.5 10 4.3 Red
BEYFS1.25-3.5 3.7mm 5.7 21.2 6.5
BEYFL1.25-3.5 3.7mm 6.4 21.2 6.5
BEYFS1.25-4 4.3mm 6.4 21.2 6.5
BEYFM1.25-4 4.3mm 7.2 21.2 6.5
BEYFL1.25-4 4.3mm 8.1 21.2 6.5
BEYFS1.25-5 5.3mm 8.1 21.2 6.5
BEYFL1.25-5 5.3mm 9.5 21.2 6.5
BEYFS1.25-6 6.5mm 9.5 21.2 6.5
BEYFL1.25-6 6.5mm 12 27.2 11
BEYF2-3 16-14
1.5-2.5
27A
1000PCS
3.2mm 5.7 21.2 6.5 10 4.9 Blue
BEYFS2-3.5 3.7mm 5.7 21.2 6.5
BEYFL2-3.5 3.7mm 6 21.2 6.5
BEYFS2-4 4.3mm 6.4 21.2 6.5
BEYFM2-4 4.3mm 7.2 21.2 6.5
BEYFL2-4 4.3mm 8.1 21.2 6.5
BEYFS2-5 5.3mm 8.1 21.2 6.5
BEYFL2-5 5.3mm 9.5 21.2 6.5
BEYFS2-6 6.5mm 9.5 21.2 6.5
BEYFL2-6 6.5mm 12 27.2 11
BEYF3.5-3 12-14
2.5-4
37A
500PCS
3.2mm 5.7 24.8 7 13.5 6.2 Black
BEYF3.5-4 4.3mm 8 24.8 7
BEYF3.5-5 5.3mm 8 24.8 7
BEYF3.5-6 6.5mm 12 28 12.1
BEYF5.5-3.5 12-10
‘4-6
48A
500PCS
3.7mm 8.3 25.2 7.5 13.5 6.7 Yellow
BEYFS5.5-4 4.3mm 8.3 25.2 7.5
BEYFL5.5-4 4.3mm 9 26 7.5
BEYF5.5-5 5.3mm 9 26 7.5
BEYFS5.5-6 6.5mm 9 26 7.5
BEYFL5.5-6 6.5mm 12 31.2 12
BEYF5.5-8 8.4mm 14 30 11.5
