Insulated Lug Terminals Electrical Lugs KSN

Specification:

Material: Copper, Tin-plated copper, Tinned Copper
Insulated material: PVC
Working Temperature: -40ºC to 150ºC
Certification: CE, RoHS, UL Approved
The Insulated Lug Terminals are made of the high-quality copper which ensures good conductivity at its user end. The Insulated Lug Terminals are tin plated to provide excellent corrosion resistance.

(In mm)

Item No. D d B L W H T
KS10-12N 9 4.5 15.5 29.5 4.3 2.4 1.1
KS16-13N 10.5 5.9 19 35 5.5 2.6 1.2
KS25-15N 11.5 7 24.5 44.5 6.8 2.6 1.2
KS35-20N 14 8.7 29.5 54 8 3.2 1.5
KS50-20N 15.8 9.8 35 61 9.5 3.8 1.8
KS70-25N 18 11.6 44 75 11 4.2 2
KS95-25N 21.6 13.7 44 75 12.5 5.2 2.5
