Specification:
4:1 shrink ratio
Low longitudinal shrinkage
Flame retardant (out jacket only)
Super sealing against water, moisture or other contaminates
Continuous operating temperature : -45℃-125℃
Shrink Temperature:125℃
Halogen-Free
Size | Expanded | After Recovery | Standard Package | |||
Inch | mm | Internal Diameter (mm) | Internal Diameter (mm) | Total Wall Thickness (mm) | Adhesive Thickness (mm) | Spool Length M/spool |
5/32 | 4 | 4 | 1 | 1.00±0.15 | 0.40±0.15 | 200 |
1/4 | 6 | 6 | 1.5 | 1.10±0.15 | 0.40±0.15 | 100 |
5/16 | 8 | 8 | 2 | 1.50±0.15 | 0.50±0.15 | 50 |
1/2 | 12 | 12 | 3 | 1.70±0.15 | 0.50±0.15 | 1.22 OR 25M/Roll |
5/8 | 16 | 16 | 4 | 2.00±0.15 | 0.60±0.15 | 1.22 OR 25M/Roll |
25/32 | 20 | 20 | 5 | 2.30±0.25 | 0.60±0.15 | 1.22 OR 25M/Roll |
1 | 24 | 24 | 6 | 2.60±0.25 | 0.60±0.15 | 1.22 OR 25M/Roll |
1-1/4 | 32 | 32 | 8 | 3.00±0.30 | 0.70±0.15 | 1.22 OR 25M/Roll |
1-1/2 | 40 | 40 | 10 | 3.00±0.30 | 0.70±0.15 | 1.22 OR 25M/Roll |
2 | 52 | 52 | 13 | 3.30±0.30 | 0.70±0.15 | 1.22 OR 25M/Roll |
