Specification:
Type | TOS 24VDC/48VDC 0,5A |
Order No. | 8950920000 |
Version | TERMOPTO, solid-state relais, 1 NO contact (Transistor), Rated control voltage: 24 V DC ±20 % , Rated switching voltage: 5…48 V DC, Continuous current: 500 mA, Screw connection |
Humidity | 5-95% relative humidity, Tu = 40°C, without condensation |
Operating temperature, max. | 60 °C |
Operating temperature, min. | -20 °C |
Storage temperature, max. | 80 °C |
Storage temperature, min. | -40 °C |
Operating temperature | -20 °C…60 °C |
Storage temperature | -40 °C…80 °C |
Rated control voltage | 24 V DC ±20 % |
Nominal control current | 7 mA DC |
Power rating | ≤ 170 mW |
Cut-in / dropout voltage | 19.2 V / 6 V DC |
Status indicator | Green LED |
Protective circuit | Varistor, Reverse polarity protection |
Rated switching voltage | 5…48 V DC |
Continuous current | 500 mA |
Rated switching current | 500 mA |
Load category | DC1 |
Switch-on delay | < 20 µs |
Switch-off delay | ≤ 600 µs |
Voltage drop at max. load | < 1 V |
Leakage current | < 10 µA |
Short-circuit-proof | No |
Protective circuit, load side | Free-wheeling diode |
max. switching frequency (DC control voltage) | 200 Hz |
