Specification:
Type | DRM270524LT |
Order No. | 7760056073 |
Version | D-SERIES DRM, Relay, No. of contacts: 2, CO contact with test button, AgNi 0,15 μm Au, Rated control voltage: 24 V AC, Continuous current: 10 A, Plug-in connection |
Rated control voltage | 24 V AC |
Rated current AC | 62.4 mA (50 Hz), 52.2 mA (60 Hz) |
Power rating | 1.0…1.2VA (60HZ) |
Pull-in/drop-out voltage, typ. | 19.2 V / 7.2 V AC |
Coil resistance | 160 Ω ± 10 % |
Status indicator | red LED |
Rated switching voltage | 250 V AC |
Max. switching voltage, AC | 250 V |
Continuous current | 10 A |
Inrush current | 20 A / 50 ms |
AC switching capacity (resistive), max. | 2500 VA |
DC switching capacity (resistive), max. | 240 W @ 24 V |
Switch-on delay | < 20 ms |
Switch-off delay | < 20 ms |
Min. switching power | 10 mA @ 12 V, 100 mA @ 5 V |
Max. switching frequency at rated load | 0.1 Hz |
Test button | yes (lockable) |
Mechanical switch position indicator | Yes |
Colour | Transparent |
UL 94 flammability rating | V-0 |
