Double Sealed Armored Cable Stuffing Glands Explosion Resistant BDAC
Specification:
Material: Stainless Steel, SS304/SS316L
Sealing: Silicone Rubber, Neoprene
Treatment of surface: Passivation
Explosion-proof: Exd IIC Gb
Flame Rating: UL94-V0
Protection Rating: IP66 – 10bar
Working Temperature:
Static state: -60°C to 100°C, short time to 120°C
Dynamic state: -20 C to 80 °C, short time to 100°C
Halogen Free
(In mm)
| Item No. | Insert thread size | Cable acceptance detail | Maximum length (H) | GL | Hex size | ||||||||
| Inner sheath/core line | Outer diameter of cable ( B) | ||||||||||||
| Metric | NPT.G | Coreline maximum | Inner sheath | Maximum core line | Min | Max | Dirction 1 | Direction 2 | Across flats | Across corners | |||
| BDAC-2-01 | M20X1.5 | 1/2″ | 9 | 10 | 6 | 5.5 | 12 | 0.9/1.25 | 0/0.7 | 65.5 | 15 | 24 | 27.7 |
| BDAC-2-01S | M20X1.5 | 1/2″ | 9 | 10 | 6 | 9.5 | 16 | 0.9/1.25 | 0/0.7 | 65.5 | 15 | 24 | 27.7 |
| BDAC-2-02 | M20X1.5 | 1/2″-3/4″ | 11.2 | 12.5 | 10 | 12.5 | 20.5 | 0.9/1.25 | 0/0.7 | 67.5 | 15 | 30 | 34.6 |
| BDAC-2-03 | M25X1.5 | 3/4″-1 | 16.3 | 18.4 | 21 | 16.9 | 26 | 1.25/1.6 | 0/0.7 | 71.4 | 15 | 36 | 41.6 |
| BDAC-2-04 | M32X1.5 | 1″-1 1/4″ | 22 | 24.7 | 42 | 22 | 33 | 1.6/2.0 | 0/0.7 | 76 | 15 | 46 | 53.1 |
| BDAC-2-05 | M40X1.5 | 1 1/4″-11/2″ | 26.5 | 29.7 | 60 | 28 | 41 | 1.8/2.5 | 0/0.7 | 78.2 | 15 | 55 | 63.5 |
| BDAC-2-06 | M50X1.5 | 1-1/2″-2′ | 37.2 | 41.7 | 80 | 36 | 52.6 | 1.8/2.5 | 0/1 | 91 | 15 | 65 | 75.1 |
| BDAC-2-07 | M63X1.5 | 2″-2 1/2″ | 47.6 | 53.5 | 100 | 46 | 65.3 | 1.8/2.5 | 0/1 | 98 | 15 | 80 | 92.4 |
| BDAC-2-08 | M75X2 | 2 1/2″-3″ | 60 | 65.3/66.2 | 120 | 57 | 78 | 1.8/2.5 | 0/1 | 102.2 | 15 | 95 | 109.6 |
