Brass Cable Gland Reinforced IP68
Specification:
Material:
Nickel-plated brass
Claw: PA66 (Nylon) , UL94-V2
Hermetic seal: NBR, Silicone rubber
O-ring: NBR, Silicone rubber
Protection rating: IP68 -10 bar
Work / Operating Temperature:
Static state: -40 °C to 100 ° C, Short time to 120°C;
Dynamic state: -20 °C to 80° C, Short time to 100°C
Certificate: CE, RoHS approved
(In mm)
| Item | Cable Range | Thread Length GL | Thread O.D. AG | Joint Length H | Spanner size | Item No. |
| MG12X1.5 | 4-8 | 8 | 12 | 18.5 | 18 | BSPMG12 |
| MG16X1.5 | 5-10 | 9 | 16 | 21.5 | 22 | BSPMG16 |
| MG20X1.5 | 10-14 | 9.5 | 20 | 25.5 | 27 | BSPMG20 |
| MG25X1.5 | 13-18 | 11 | 25 | 28 | 30 | BSPMG25 |
| MG32X1.5 | 18-25 | 12.5 | 32 | 33 | 40 | BSPMG32 |
| MG40X1.5 | 25-32 | 15 | 40 | 35 | 50 | BSPMG40 |
| MG50X1.5 | 32-42 | 15 | 50 | 40 | 59 | BSPMG50 |
| MG63X1.5 | 35-45 | 17 | 63 | 45 | 67 | BSPMG63 |
